The KODAK Portrait 3D Printer is a reliable manufacturing system, capable of producing
end-use parts in a wide variety of materials. Its solid steel structure, quality components and
careful design result in a high uptime with low maintenance costs.
The KODAK Portrait 3D Printer has been created for consistency in production and ease of use at a professional level. Its sleek design and straightforward software make it a great choice in an educational capacity, while its dual extrusion and heat-controlled print compartment allow this 3D Printer to create the level of functionality within a design office setting.
Access our remote management platform via Wi-Fi or the LAN port to slice online, monitor your prints, store and share files, administer a print farm and download over-the-air updates, among other functions.
For use in offices, factories or educational institutions, the enclosed chamber with air filtration keeps toxic particles and unwanted odors inside the printer, while keeping fingers away from hot, moving parts.
The fully enclosed print chamber lets you print with more advanced materials such as ABS and Nylon, that would warp in an open printer, especially large objects.
In terms of safety, except for PLA, most materials should be printed with a closed chamber with eﬀective air filtering to prevent irritating and toxic fumes and smells.
Adding an enclosure to a printer that was not designed that way introduces potential heating problems and aﬀects print profiles that were not designed for that environment.
Filaments absorb humidity from the air, even after only a few hours. We provide sealed protective cases for our filaments that prevent humidity and dust from aﬀecting the print quality.
The KODAK Portrait features a dual extrusion system engineered for multi-material compatibility, consisting of several components:
|Build volume||single extrusion: 215 x 210 x 235 mm (8.5 x 8.3 x 9.3”)
dual extrusion: 170 x 210 x 235 mm (6.7 x 8.3 x 9.3”)
|Hotends||dual extrusion with automatic nozzle lifting, 1 PTFE and 1 all metal|
|Nozzles||0.4 mm standard, compatible with the full E3D line|
|Bed leveling||automatic, active Z compensation|
|Display||5” color touchscreen|
|Structure||2 mm steel|
|XY motion||Linear bearings, 12mm|
|Z motion||Precision ballscrew, 12mm|
|Connectivity||Wi-Fi, Ethernet LAN port, USB drive|
|Monitoring||8 Mpx live camera|
|Lights||color LED lights indicating printer status|
|Z-axis resolution||50 micron|
|XY resolution||0.2 mm|
|Maximum nozzle temperature||295ºC hotend 1, 240ºC hotend 2|
|Maximum build plate temperature||120ºC|
|Power requirements||110/230V – Auto Switching, 50-60Hz 320W max|
|Print controller||32 bits|
|Logic processor||32 bits, quad-core|
|Operating ambient temperature||10 – 30 ºC|
|Slicer file types||3DS, 3MF, AMF, OBJ, and STL|
|KODAK 3D Cloud|
|KODAK 3D Slicer|
|Supported OS||MacOS, Windows, Linux|
|Filament compatibility||KODAK PLA+, PLA Tough, ABS, Nylon 6, Nylon 12, Nylon 6/6.6/12, PETG, PVA, Flex98, HIPS, Acrylic and third-party materials|
|Filament diameter||1.75 mm|
|Physical dimensions||455 x 435 x 565 mm|
|Dimensions with spool holders||455 x 530 x 565 mm|
|Net weight||24.4 kg|
|Shipping weight||35.1 kg|
|Shipping box dimensions||560 x 530 x 730 mm|
|Supplied filaments||1 PLA Tough, 1 PLA+|
|Filament protection cases||2|
|Toolkit||Case with various tools, cloth cover, build surface adhesive|
|Certifications||Safety (UL 60950-1)
Electrical interference (FCC Part 15 Subpart B for Class A, ETSI EN 301 489-1/17)
CE Declaration of Conformity
|KODAK 3D Cloud||
The KODAK 3D Cloud is built into every printer, is free to use, and provides remote operation functionality, without the need to install software on your workstation.
Thanks to the cloud system, you don’t need to be physically in front of the printer to use. No longer in the office? No problem. You can launch a print through your home computer or even from your phone, whilst walking down the street. You can remotely upload models, slice them, prepare them and launch the print. Thanks to the built in camera, you can even monitor your print as a live stream, direct to your cloud account. Sign up for free.
|KODAK 3D Slicer||
Based on Cura, the desktop version of our slicer gives you the freedom of not having to be connected to the internet and of avoiding the sometimes slow file transfers of large files. It features all the same power as the Cloud version.
The KODAK Desktop Slicer is built on top of the popular Cura slicing engine. It comes with a full set of optimized print profiles. Use it to get the best print results with your KODAK 3D Printer, with no file transfer delays and without needing to be online. Available for all major operating systems. Download now.
|Training||Our courses are designed to take you from complete novice to an expert user of 3D Printers, 3D Scanners, Software and materials. Being able to install, operate and solve technical issues without the need for a technician. Training is available online or via our dedicated technical team for more information see our training options.|
|Lifetime support||Expert technical support via email, phone, or from our global community is available to you for the lifetime of your printer. How can we help you?.|
3DGBIRE offers a Warranty Extension to the Manufacturer Warranty, this extends the Warranty from 12 months to cover 36 months from the date of purchase.
Warranty extension includes:
*The Printcores are excluded from the warranty. **Excludes cost of carriage
