HP Jet Fusion 5200 Series 3D Printer

Drive new growth and expand into volume production with HP’s robust, manufacturing-ready 3D printing solution.

Price on Request

To get a quote on this product and how you can implement the technology into your business and generate results immediately, contact our 3DGBIRE team. We’d love to hear about your project and help you find the right solution.

Call our dedicated Business Solutions Team and find out how 3D printing can revolutionise your business.

Click "Make an Enquiry" below, Call 01257 228411 or send an email to sales@3dgbire.com

Features Specification Videos

HP Jet Fusion 5200 Series Rebuild

Industrial 3D Printing Solution

Drive new growth and expand into volume production with HP’s robust, manufacturing-ready industrial 3D printers.

Explore the complete HP Jet Fusion 5200 Series 3D Printing Solution

HP 3D High Reusability PP5 enabled by BASF

Chemical resistant,6 weldable, low moisture absorption, functional parts

HP 3D High Reusability PA 118

Ductile,9 quality parts

Data courtesy7

HP 3D High Reusability PA 1211

Strong, low cost,12 quality parts

Data courtesy10

HP 3D High Reusability PA 12 GB14

Stiff, dimensionally stable, quality parts

Data courtesy13

BASF Ultrasint® TPU01

Flexible, functional parts.

Data courtesy15

HP Jet Fusion 5200 Series 3D Automatic Unpacking Station

Achieve consistent unpacking results through an automatic process with an industrial-grade solution.

HP 3D API2

Streamlined data access and automation across industrial management systems2

HP 3D Center1

Dashboard view into production data and remote monitoring for greater efficiency and agility.

HP 3D Process Control4

Dimensional accuracy and repeatability—faster—for manufacturing predictability.

HP SmartStream 3D Build Manager

Quickly and easily prepare your jobs for printing with all the elements you need.

Autodesk® Netfabb® with HP Workspace

Provides advanced software for the additive manufacturing of production quality parts.

HP Build Processor

The industry standard software for professional 3D Printing, to unlock the full potential to manage every step in your production process.

Siemens NX AM

Combine design, optimization, simulation, preparation of print jobs, and inspection processes all in a single managed environment and with minimal steps.

HP Jet Fusion 5200 3D Natural Cooling Unit

Designed to remove and cool each build naturally, thereby enabling continuous production.

Hovmand Forklift 5200

HP recommended accessory to remove and place the HP Jet Fusion 5200 3D Natural Cooling Unit from the processing station.

HP 3D Solution Services

Explore new opportunities to scale production and accelerate growth with support and consultancy from HP.

HP 3D as a Service

Pay based on usage: Gain new levels of cost predictability and the flexibility to scale your business as you grow.

HP Integrated Financial Solutions

Accelerate your time to value. Enjoy the flexibility to meet both your technology and financial plans while allocating your cash to other priorities.

Technical specifications

Printer	2210 x 1268 x 1804 mm (87 x 50 x 71 in)
Shipping	2300 x 1325 x 2027 mm (91 x 52 x 80 in)
Operating area	a 3700 x 3700 x 2500 mm (146 x 146 x 99 in)
Weight (Printer)	880 kg (1940 lb)
Weight (Build unit)	140.5 kg (309.7 lb)
Weight (Shipping)	1037.5 kg (2287 lb)
Technology	HP Multi Jet Fusion technology
Power Consumption	12 kw22
Power Requirements	380-415 V (line-to-line), 50 A max, 50/60 Hz 200-240 V (line-to-line), 80 A max, 50/60 Hz

Effective building volume	380 x 284 x 380 mm (15 x 11.2 x 15 in)
Building speed	Up to 5058 cm³/hr (309 in³/hr)
Layer thickness	0.08 mm (0.003 in)
Job processing resolution (x, y)	1200 dpi
Print resolution (x, y)	1200 dpi

Network	Gigabit Ethernet (10/100/1000Base-T), supporting the following standards: TCP/IP, DHCP (IPv4 only), TLS/SSL
Processor	Intel® Core™ i7 7770 (3.6 GHz, up to 4.2 GHz)
Memory	32 GB DDR4
Hard disk	1TB HDD SED (AES-256 encrypted) 1TB SDD SED (AES-256 encrypted), TGC-OPAL 2.01 compliant
Software	HP SmartStream 3D Build Manager HP SmartStream 3D Command Center
Compatible software	HP 3D API, HP 3D Center, HP 3D Process Control, HP Universal Build Manager powered by Dyndrite
Supported file formats	3MF, STL, OBJ, and VRML (v2.0)
Certified third-party software	Autodesk® Netfabb® with HP Workspace, Materialise Build Processor for HP Multi Jet Fusion technology, Siemens NX AM for HP Multi Jet Fusion technology

Training	Our courses are designed to take you from complete novice to an expert user of 3D Printers, 3D Scanners, Software and materials. Being able to install, operate and solve technical issues without the need for a technician. Training is available online or via our dedicated technical team for more information see our training options.
Warranty period	One-year limited hardware warranty
Lifetime support	Expert technical support via email, phone, or from our global community is available to you for the lifetime of your printer. How can we help you?.
Extended support	Online resources, extensive manuals (in multiple languages), material technical and safety data sheets (in multiple languages), a detailed knowledge base, and much more.
